1. products are used in rail transportation such as high speed rail, subway, city rail and so on. 2. product design through low noise technology, strong overload capacity, high impedance short circuit capacity, high mechanical strength, high anti harmonic, high vibration resistance, large current impact resistance and thermal shock without cracking, free suspension structure etc..
Locomotive Application reactor product description:
1. products are used in rail transportation such as high speed rail, subway, city rail and so on.
2. product design through low noise technology, strong overload capacity, high impedance short circuit capacity, high mechanical strength, high anti harmonic, high vibration resistance, large current impact resistance and thermal shock without cracking, free suspension structure etc..
|
Technical Parameters of DC Reactor for Rail Transit |
|||
|
Item |
Standard Value |
Condition |
|
|
1 |
Inductance value |
0.1mH-100mH |
|
|
2 |
Current range |
＜2000A |
|
|
3 |
Insulation resistance |
＞100M? |
DC1000V |
|
4 |
Dielectric strength |
＜20mA |
AC5.5KV 60s |
|
5 |
Noise |
≤75dB |
1m away from transformer |
|
6 |
Temperature rise |
≤125K |
Full load, forced air cooling |
|
7 |
Insulation class |
Class H (180℃) |
|
|
8 |
Ambient temperature |
-40℃ - 50℃ |
|
|
9 |
Design standard |
GBT10229 |
|
|
|
Rail transit |
